MNS DTR / MNS Service
7
1.1 Technical data
Standards
Type-tested switchgear assemblies (TTA)*
Low-voltage switchgear and control gear assem-
blies **
Power switchgear and control gear assemblies **
IEC 60439-1,
IEC 61439 -1 and -2
EN 61439-1 and -2
Test certificates
Germanischer Lloyd, Hamburg / Germany
ASTA, UK
IPH, Institut für Prüffeld- und Hochspannungstechnik, Berlin / Germany
DLR German Research Institute for Aerospace e. V., Jülich / Germany
IABG Industrieanlagen Betriebsgesellschaft, München / Germany
Electrical
data
Rated voltages
Rated insulation voltage U
i
Rated operating voltage U
e
Rated impulse withstand voltage U
imp
Overvoltage category
Degree of pollution
Rated frequency
1000 V 3~, 1500 V- **
690 V 3~, 750 V-
6 / 8 / 12 kV, depending on equipment
II / III / IV
3
up to 60 Hz
Rated currents
Busbars:
Rated current I
e
Rated peak withstand current I
pk
Rated short-time withstand current I
cw
Distribution bars:
Rated current I
e
Rated peak withstand current I
pk
Rated short-time withstand current I
cw
up to 6300 A
up to 250 kA
up to 100 kA
up to 2000 A
up to 176 kA
up to 80 kA
Mechanical
character-
istics
Dimensions
Cubicles and frames
Recommended height
Recommended width
Recommended depth
Basic grid size
DIN 41488
2200 mm
400, 600, 800, 1000, 1200 mm
400, 600, 800, 1000, 1200 mm
E = 25 mm acc. to DIN 43660
Surface protection
Frame
Internal subdivision
Enclosure
Zinc or Alu-zinc coated
Zinc or Alu-zinc coated
Zinc or Alu-zinc coated and
Powder coated RAL 7035, light grey
Degrees of
protection
According to IEC 60529
IP 30 up to IP 54
Plastic components
Halogen-free, self-extinguishing,
flame retardant, CFC-free
IEC 60707, DIN VDE 0304 part 3
Internal
subdivision
Device compartment - device compartment
Busbar compartment - cable compartment
Busbar compartment - device compartment
Device compartment - cable compartment
Form 4
Extras
Paint finish
Enclosure
Special colours (standard RAL 7035)
Busbar system
Busbars
Insulated
Silver or tin galvanized
* Definition TTA: Switchgear assembly corresponding, to a large degree, with the original type or system of switchgear assembly type-tested
in accordance with these standards.
** Design verification by testing: When an assembly has previously been tested in accordance with IEC 60439-1 , and the results fulfil the
requirements of IEC61439 -1 / -2, the verification of these requirements need not to be repeated
*** Depending on the electrical equipment.

ABB MNS Specifications

General

Modular Design	Yes
Busbar Material	Copper or Aluminum
Type	Low Voltage Switchgear
Form of Internal Separation	Form 4b
Ingress Protection	Up to IP54
Standards	IEC 61439
Installation Type	Fixed, withdrawable
