Chapter 4 – Electrical Installation
NCAN-02 Installation and Start-up Guide 4-3
Make the required
settings.
3
SW1
SW2
1
ON
ON
8
1
4
Node No. Binary SW1
*1 0000001
2 0000010
• • • • • • • • •
127 1111111
ON DIP
12345678
ON DIP
12345678
ON DIP
12345 678
Function SW1
SW1 and SW2 enabled –
node no. and baud rate
selected with DIP switches.
*SW1 and SW2 disabled –
node no. and baud rate
selected with parameters.
ON DIP
123456 78
ON DIP
12345678
Baud Rate Binary SW2 Baud Rate Binary SW2
1 Mbit/s 000 100 kbit/s 100
500 kbit/s 001 50 kbit/s 101
250 kbit/s 010 20 kbit/s 110
*125 kbit/s 011 10 kbit/s 111
ON DIP
1234
ON DIP
1234
ON DIP
1234
ON DIP
1234
ON DIP
1234
ON DIP
1234
ON DIP
1234
ON DIP
1234
*Default setting
