Appendix A – CANopen Error Codes
A-2 NCAN-02 Installation and Start-up Guide
ACS 400
CANopen Error Drive Fault
Register
Bit
Code Meaning Name
Additional
Information
b0 1000 Generic error HW error: Sporadic fault interrupt Fault Word 2, b13
b1 2310 Continuous overcurrent Overcurrent Fault Word 1, b0
Output overload Fault Word 1, b4
b1 2320 Short circuit / Earth leakage Fault current Fault Word 1, b3
b1 2330 Earth leakage Output earth fault Fault Word 1, b15
b2 3110 Mains overvoltage DC overvoltage Fault Word 1, b1
b2 3130 Phase failure DC bus ripple too large Fault Word 1, b11
b2 3220 DC link undervoltage DC undervoltage Fault Word 1, b5
b3 4210 Excess temperature device ACS 400 overtemperature Fault Word 1, b2
b3 4310 Excess temperature drive Motor overtemperature Fault Word 1, b8
b5 5210 Measurement circuit
HW error: Bad analogue input; invalid pulse
count
Fault Word 2, b11
b5 5300 Operating unit Panel loss Fault Word 1, b9
b5 5530 EEPROM HW error: Bad or new FPROM Fault Word 2, b8
HW error: New FPROM detected Fault Word 2, b9
HW error: Unsuccessful FPROM download Fault Word 2, b10
b5 6320 Parameter error Parameters inconsistent Fault Word 1, b10
b5 7121 Motor blocked Motor stall Fault Word 1, b12
b5 7510 Serial interface 1 DDCS link Fault Word 2, b2
b5 7520 Serial interface 2 Serial communication loss Fault Word 1, b13
b5 8110 Process data monitoring Analogue input 1 fault Fault Word 1, b6
Analogue input 2 fault Fault Word 1, b7
b5 9000 External error External fault Fault Word 1, b14
b7 FF55 Drive specific HW error: Modulator stalled Fault Word 2, b15
b7 FF57 Drive specific Type code error Fault Word 2, b12
b7 FF5D Drive specific Application fault Fault Word 2, b1
b7 FF5E Drive specific HW error: SW assert expired Fault Word 2, b14
b7 FF6A Drive specific Underload Fault Word 2, b0
