Chapter 5 – Programming
5-4 NCAN-02 Installation and Start-up Guide
CUT-OFF TIMEOUT This parameter defines the time after which the NCAN-02 makes a
self-reset and thus stops communicating (with the drive and the
master) in case the PDO communication between the NCAN-02 and
the master fails. Cut-off supervision is activated upon a successful
receipt of a PDO, i.e. this parameter has no effect if no messaging has
taken place.
The actual timeout in seconds is the value of this parameter (1 ... 255)
divided by 10. Setting the parameter to 0 disables cut-off supervision.
0 (disabled); 1 … 255
STATUS This parameter indicates the status of the NCAN-02 module.
DATA SET OFFSET This parameter selects the number of the first data set to be used for
fieldbus communication. By default, the value of this parameter is FBA
D SET 1, denoting that data sets from no. 1 onwards are used for
communication with the drive. However, some drives reserve these
data sets for other use, and thus it may be necessary to use other data
sets. Setting this parameter to the value of FBA D SET 10 makes data
set 10 the first data set to be used for the communication between the
NCAN-02 and the drive.
FBA D SET 1; FBA D SET 10
NO. OF DATA SETS This parameter defines the number of data sets and activated PDOs
sent in each direction.
1 ... 4
Value Description
(0) SELF TEST Module initialising and performing self-test.
(1) RX Q OVERRUN Software overrun. No space in high-priority receive queue
to store message. Message discarded.
(2) CAN OVERRUN Overrun bit in status register of CAN controller set.
(3) BUS OFF CAN controller state switched to BUS OFF.
(4) ERROR SET – Error status bit in status register of CAN controller set, or
– Self-test error, or
– Cut-off timeout expired, or
– CAN controller initialisation failed.
(5) ERROR RESET Error status bit in status register of CAN controller reset.
(6) TX Q OVERRUN Software overrun. High-priority transmit queue full.
(7) DISCONNECTED Node state changed to DISCONNECTED.
(8) STARTED Node started.
(9) STOPPED Node stopped.
(10) G FAILS Node not guarded within node life time.
(11) PRE-OPERAT. Node state changed to PRE-OPERATIONAL.
(12) RESET COMM. Reset communication indication received.
(13) RESET NODE Reset node indication received.
