32
MOTORIZED CHANGE-OVER AND TRANSFER SWITCHES, OTM_C
Figure 10.3 Mounting of the bridging bars (type OTZC_) to the motorized change-over switches
OTM1000-1600E_C_ and OTM800-1200U_C_
A04189
OTZC_
II
2
1
3
OTZC43, OTZC44
OTM1000-1250E_C
OTZC53, OTZC54
OTM1600E_C
OTM800-1200U_C
