33
MOTORIZED CHANGE-OVER AND TRANSFER SWITCHES, OTM_C
MOTORIZED CHANGE-OVER AND TRANSFER SWITCHES, OTM_C
Figure 10.4 Mounting of the bridging bars (type OTZC_) to the motorized change-over switches
OTM2000-2500E_C_
A04190
II
I
OTZC_
3
1
2
OTZC63, OTZC64
OTM2000-2500_C_
