AE 01 ASi power missing. Automatically reset
AE 02 No connection with ASi master (in Monitor mode). Automatically reset
AE 03 Safety code missing by code teaching. Teach AS-i safety codes
AE 04 Wrong code table. Teach AS-i safety codes
AE 05 Internal AS-i fault. Reboot
AC [node no] Channel fault in safety node. Switch off both channels
Ab [node no] AS-i slave with bad or wrong safety code. Routine “Single slave
exchange” or teach safety
codes (PC) or exchange
defect slave.
An [node no] Slave profile does not match. Read AS-i slaves (with PC)
CC [node no] Code Change. Pluto prepared for exchange of safety
slave, one slave is missing.
(Acknowledge with “K” button.)
CC Code Change. Pluto is prepared for connection of new
safety slave.
CF Code Found. Code in new safety slave is available.
(Acknowledge with “K” button.)
Cd Code Duplicate. Code already stored in Plutos code
table.
AS-i LEDs
The status of the AS-i LEDs does not give any additional information than what is already given by
the error code (except in one case as illustrated by the table below), but green LED off and/or red
LED on indicates an error.
Green LEDs Red LEDs
Off On Yes ASi power missing See Error code
On On Yes AS-i fault See Error code
On On No Pluto in Slave mode not
addressed by master
Configure master
In-/Output LEDs
The status of the Input and Output LED’s gives additional information for troubleshooting.
