10 CI/EDP300-EN Rev. C | PositionMaster EDP300
Option modules
Module for the emergency shutdown function
Terminals +85 / -86
Temperature class T1 – T6
U
i
= 30 V
P
i
= 1 W
C
i
= 5.3 nF
L
i
= negligibly small
Module for analog feedback (AO)
Terminals +31 / -32
Temperature class T1 – T4 Temperature class T6
U
i
= 30 V U
i
= 28 V
I
i
= 320 mA I
i
= 320 mA
P
i
= 1 W P
i
= 0.8 W
C
i
= 11.3 nF
L
i
= 150 µH
Module for universal input (UAI)
Terminals +21 / -22
Temperature class T1 – T4 Temperature class T6
U
i
= 30 V U
i
= 28 V
I
i
= 320 mA I
i
= 320 mA
P
i
= 1 W P
i
= 0.8 W
C
i
= 11.3 nF
L
i
= 150 µH
Module for digital feedback (SW1 / SW2)
Terminals SW 1: +41 / -42
SW 2: +51 / -52
Temperature class T1 – T4 Temperature class T6
Per output: Per output:
U
i
= 30 V U
i
= 28 V
P
i
= 0.5 W P
i
= 0.4 W
I
i
= 250 mA
C
i
= 2.2 nF per output
L
i
= negligibly small
Limit switch (Limit 1 / Limit 2)
Limit monitor with proximity switch
1)
Terminals Limit 1: +51 / -52
Limit 2: +41 / -42
Temperature class T1 – T4 Temperature class T6
-25 … 85 °C -25°C … 40°C
1) No IECEx approval
