28 CI/EDP300-EN Rev. C | PositionMaster EDP300
7 Commissioning
7.1 Safety instructions
NOTICE
The electrical power supply and supply air pressure data
indicated on the name plate must be complied with during
commissioning.
Before switching on the device, make sure that your
installation complies with the environmental conditions listed in
the chapter “Technical Data” or on the data sheet.
If there is a chance that safe operation is no longer possible,
take the device out of operation and secure it against
unintended startup.
7.2 Checks prior to commissioning
Air pressure in the compressed air connecting line:
1.4 … 10 bar (20 … 145 psi)
Current input active:
4 … 20 mA
7.3 Mechanical mounting checks
During commissioning, the mechanical mounting on the linear
and rotary actuators is checked. For this purpose, the actuator
is first moved into the end positions and Auto Adjust is then
carried out.
With large actuators, it can occur that the time for automatic
adjustment is significantly than in smaller actuators.
7.3.1 Moving to end positions following completion of
Auto Adjust
Process display
1. Use to switch to the Operating Mode menu.
Operating mode
Auto Ad
ust
O Ada
tive
O Control
O Manual SP
O Manual Senso
Confi
uration
Back OK
2. Use or to select the "Manual Sensor" operating
mode.
3. Use and to move to the relevant end positions.
-45.0
Pos. Ang. °
Check the end positions. The angle of rotation is displayed in
degrees.
Recommended range:
— between -30 … 30° for linear actuators
— between -45 … 45° for rotary actuators
7.3.2 Moving to end positions with a new device
Process display
Electronics
Use and to move to the relevant end positions.
-45.0
Pos. Ang. °
Check the end positions. The angle of rotation is displayed in
degrees.
Recommended range:
— between -30 … 30° for linear actuators
— between -45 … 45° for rotary actuators
Auto Adjust must then be performed.
"Start Auto Adjust function" on page 31
