Softstarters Type PSE18...PSE370 User Manual short form 1SFC132059M9901 13
EN
Description Display Setting range Default
value
Actual
setting
Rated Current of motor
Individual Individual
Start Ramp time
1...30 s 10 s
Stop Ramp time
OFF, 1...30 s OFF
Initial/End Voltage
30...70 % 40 %
Current Limit
1.5...7 x I
e
7.0 x I
e
Torque Control during start
ramp
OFF, On OFF
Torque Control during stop
ramp
OFF, On On

OFF, 30...100 % OFF
Electronic Motor Overload
Protection (EOL)
Tripping class
Type of operation
OFF, 10A, 10, 20, 30
HAnd, Auto
1
10
HAnd
Underload Protection
Level
Type of Operation
OFF, 0.2...1 x I
e
HAnd, Auto
1
OFF
HAnd
Locked Rotor Protection
Level
Type of Operation
OFF, 0.5...7 x I
e
HAnd, Auto
1
OFF
HAnd
FieldBus Control
Fieldbus Address
Download Parameter
Operation When Fault
Type of Operation
OFF, On
2
0...255
dPon, dPoF
4
trIP, LocC
5
HAnd, Auto
6
OFF
255
3
dPon
LocC
HAnd
Table 6.1: Parameter list
HAnd = Manual reset of the protection or fault.
Auto = Automatic reset of the protection or fault.
OFF = Fieldbus is not allowed to control the motor.
On = Fieldbus is allowed to control the motor.
255 = Address of the FieldBusPlug will be used.
dPon = Download of parameters from PLC enabled.
dPoF = Download of parameters from PLC blocked.
Accessible only if On is previously selected.
trIP = Trip on fault.
LocC = Local control on fault - hardwire control is pos-
sible
Accessible only if trIP is previously selected.
HAnd = Manual reset of the protection or fault.
Auto = Automatic reset of the protection or fault.
1
2
4
5
6
3
