PST(B) – The advanced range
Technical data
Major possible settings and the displayed text and the set default values
Description Text on display (Eng) Values on display Default value
Setting current for overload, locked rotor etc. Setting I
e
9.0 ...1207 A divided into 19 overlapping ranges. See table, page 48
Time for start ramp Start Ramp 1 ... 30 s, 1 ... 120 s (Range depends on Start Range) 10 s
Time for stop ramp Stop Ramp 0 ... 30 s, 0 ... 120 s (Range depends on Stop Range) 0 s
Initial voltage for start ramp Init Volt 30 ... 70 % 30 %
End voltage for stop ramp End Volt 30 ... 70 % 30 %
Step down voltage Step Down 30 ...100 % 100 %
Level of the current limit. Current Lim 1.5 ... 7.0 x I
e
4.0 x I
e
Selection of Kick start Kick Start Yes, No No
Level of Kick start if selected Kick Level 50 ... 100 % 50 %
Time for Kick start if selected Kick Time 0.1 ... 1.5 s 0.2
Selectable range for start ramp Start Range 1 ... 30 s, 1...120 s 1 ... 30 s
Selectable range for stop ramp Stop Range 0 ... 30 s, 0 ... 120 s 0 ... 30 s
Overload protection Overload No, Normal, Dual Normal
Overload Class OL Class 10 A, 10, 20, 30 10
Overload Class, Dual type, Start Class OL Class S 10A, 10, 20, 30 10
Overload Class, Dual type, Run Class OL Class R 10A, 10, 20, 30 10
Type of operation for overload protection OL Op Stop-M, Stop-A, Ind Stop-M
Locked rotor protection Locked Rotor Yes, No No
Trip level for locked rotor protection Lock R Lev 0.5 ... 8.0 x I
e
4.0 x I
e
Trip time for locked rotor protection Lock R Time 0.2 ... 10 s 1.0 s
Type of operation for locked rotor protection Lock R Op Stop-M, Stop-A, Ind Stop-M
Underload protection Underload Yes, No No
Trip level for Underload protection Underl Lev 0.4 ... 0.8 x I
e
0.5 x I
e
Trip time for Underload protection Underl Time 1 ... 30 s 10 s
Type of operation for Underload protection Underl Op Stop-M, Stop-A, Ind Stop-M
Phase imbalance protection Phase Imb Yes, No No
Trip level for phase imbalance protection Ph Imb Lev 10 ... 80 % 80 %
Type of operation for phase imbalance protection Ph Imb Op Stop-M, Stop-A, Ind Stop-M
High current protection High I Yes, No No
Type of operation for high current protection High I Op Stop-M, Stop-A, Ind Stop-M
Phase reversal protection Phase Rev Yes, No No
Type of operation for phase reversal protection Ph Rev Op Stop-M, Stop-A, Ind Stop-M
PTC protection PTC Yes, No No
Type of operation for PTC protection PTC Op Stop-M, Stop-A Stop-M
An external Bypass contactor is used Ext ByPass Yes, No No
High current warning Warn I=High Yes, No No
Trip level for high current warning Wa I=H Lev 0.5 ... 5.0 x I
e
1.2 x I
e
Low current warning Warn I=Low Yes, No No
Trip level for low current warning Wa I=L Lev 0.4 ...1.0 x I
e
0.8 x I
e
Overload warning Warn OL Yes, No No
Trip level for overload warning Wa OL Lev 40 ... 99 % 90 %
Thyristor overload warning Warn SCR OL Yes, No No
Type of operation for phase loss fault Ph Loss Op Stop-M, Stop-A Stop-M
Type of operation for by-pass doesn’t close BP open Op Stop-M, Stop-A Stop-M
Type of operation for by-pass doesn’t open BP closed Op Stop-M, Stop-A Stop-M
Type of operation for eldbus fault FB Fault Op Stop-M, Stop-A Stop-M
Type of operation for frequency fault Freq F Op Stop-M, Stop-A Stop-M
Type of operation for heat sink over temperature fault HS Temp Op Stop-M, Stop-A Stop-M
Type of operation for thyristor short circuit fault SCR SC Op Stop-M, Stop-A Stop-M
Function of programmable input In_0 In0 None, Reset, Enable, Jog, DOL, Start 2, FB-Dis Reset
Function of programmable input In_1 In1 None, Reset, Enable, Jog, DOL, Start 3, FB-Dis Reset
Function of programmable relay output K4 Relay K4 Run, TOR, Event Run
Function of programmable relay output K5 Relay K5 Run, TOR, Event TOR
Function of programmable relay output K6 Relay K6 Run, TOR, Event Event
Control of the softstarter with eldbus Fieldb Ctrl Yes, No No
Number of sequences for sequence start. No of Seq No, 2, 3 No
Language to use on display Language US/UK, FI, SE, PT, NL, IT, FR, ES, DE, CN, RU, TR, PL, CZ US/UK
Password for display Password No, 1 ... 255
Start mode Start Mode Volt, Torque Volt
Stop mode Stop Mode Volt, Torque Volt
Torque limit Torque limit 20 ... 200 % 150 %
Analog output Analogue Out Yes, No No
Analog output, reference Anl Ref 0 ...10 V, 0 ... 20 mA, 4 ... 20 mA 4 ...20 mA
Analog output, type of value Anl Type I Amp, U Volt, P kW, P hp, Q kVAr, S kVA, TmpMot, TmpSCR, cosPhi I Amp
