ABB PVS-175-TL - Safety and Accident Prevention

6 Quick Installation Guide - PVS-175-TL “A.1 Version”
EN
Power module internal view
33 DC interface cables 35 Interface signal connectors (male) 36 Interface protective earth point
34
AC interface
connection point
35
34
34
33
36
