7
EN
Communication board
37
ABB RS485 service Ethernet
connector (RJ45) (service only)
41 Alarm terminal block 45 Ethernet connector 1 (RJ45)
38
RS485 ABB service 120Ohm
termination res. (service only)
42
Remote ON/OFF terminal
block
46 USB connector
39 DRM0 activation switch 43 RS485 line terminal block 47 CR2032 Backup battery
40 RS485 line 120Ohm termination res. 44 Ethernet connector 2 (RJ45)
J9 J10
X2
J2
S2
J4
J1
S1 S3
J3
J6
47
37
41
39
40
42
38
43
46
44
45
