2.0 ED2.0 BOARDS AVAILABLE/MAGNETIC ACTUATOR COIL ENERGIZING CAPACITOR
1. Low voltage full optional board Part Number 751010-809 (24 – 60 VDC or 24 – 48 VAC).
2. High voltage full optional board Part Number 751010-810 (110 – 280 VDC or 100 – 254
VAC).
3. 0.1 microfarad aluminum electrolytic capacitor Part Number 12A01272H01.
3.0 ED2.0 CONTROL BOARD HIGHLIGHTS
IMPORTANT ELECTRONIC DRIVE BOARD FEATURES
ILLUSTRATION 2 – MAIN ED2.0 BOARD FEATURES
Page 30
FEATURE
BINARY INPUTS 6
FAST/SLOW INPUT FAST OR SLOW
BINARY OUTPUTS 7
WRONG POSITION AUTO TRIP YES
CAPACITOR VOLTAGE MONITOR YES
COIL CONTINUITY MONITOR YES
PROTECTION TRIP INPUT YES
SAFE OPEN YES
UNDER VOLTAGE AUTO TRIP YES
ENERGY FAIL AUTO TRIP YES
AUXILIARY CAPACITOR
CHARGE/DISCHARGE YES
OUTPUT POWER REDUCTION
(33 W) YES
JTAG PORT FOR SERVICE AND
UPGRADE DOWNLOAD YES
RS232 PORT FOR SERVICE
DOWNLOAD YES
TEMPERATURE PROTECTION YES
INRUSH LIMIT YES
