9.0 ED2.0 BOARD CONNECTORS
KM1001 – MAGNETIC ACTUATOR POSITION (CB POSITION)
KM1002 – POWER OUTPUT AND CAPACITOR LINK
KM1001-1 OFF SIGNAL
KM1001-2 ON SIGNAL
KM1001-3 +18 VDC
KM1001-4 +18 VDC
KM1001-5 ELECTRONIC GROUND (0 VDC)
KM1001-6 ELECTRONIC GROUND (0 VDC)
KM1002-1 CAPACITOR PLUS (+80 VDC)
KM1002-2 CAPACITOR PLUS (+80 VDC)
KM1002-3 CAPACITOR MINUS (0 VDC)
KM1002-4 CAPACITOR MINUS (0 VDC)
KM1002-5 + CLOSE COIL (+80 VDC)
KM1002-6 + CLOSE COIL (+80 VDC)
KM1002-7 + TRIP COIL (+80 VDC)
KM1002-8 + TRIP COIL (+80 VDC)
KM1002-9 - CLOSE COIL
KM1002-10 - CLOSE COIL
KM1002-11 - TRIP COIL
KM1002-12 - TRIP COIL
Page 46
