10.0 DEFAULT JUMPER AND DIP SWITCH SETTINGS
Unless specified by the customer, the Low Energy and Under Voltage trip functions are
disabled. The control inputs are set to the “slow” mode (10 millisecond minimum pulse width).
Input three is set for Auxiliary trip mode as opposed to the Protection Relay trip mode. The
Protection Relay mode has a lower switching threshold (12 V). See Illustration 13 in Appendix
A for Switch and Jumper locations. The following represents the functional Jumper and Dip
Switch settings which are the shipped configuration.
Jumper JP1001 (Auxiliary/Protection Relay Input) – Pins 2 to 3.
Dip Switch I1001 (Under Voltage Range)
Position 1 – ON
Position 2 – ON
Position 3 – ON
Dip Switch I1002 (Fast/Slow Input. Position 4 sets Input 3 as Auxiliary or Safe input)
Position 1 – ON
Position 2 – ON
Position 3 – ON
Position 4 – OFF
Dip Switch I1004 (Low Energy Trip/Under Voltage Delay and Enable)
Position 1 – OFF
Position 2 – OFF
Position 3 – OFF
Position 4 – OFF
Position 5 – OFF
