DIP SWITCH I1001
Under Voltage threshold setting. See Illustration 12 for setting instructions.
DIP SWITCH I1002
Sets input response delay for slow (10 milliseconds) or fast (2 milliseconds). Also sets input 3
for either aux or safe input mode.
DIP SWITCH I1004 – LOW ENERGY AUTO TRIP AND UNDER VOLTAGE
DELAY FUNCTIONS
For setting instructions see Illustration 12. The UV Function is enabled by selecting an
appropriate delay with I1004 and also selecting an appropriate range with I1001.
DIP SWITCH I1005 (FUTURE USE ONLY)
JUMPER JP1001
Sets input number 4 to either normal (pins 2 to 3) or as a protection input (pins 1 to 2).
JUMPER JP1005 (ABB USE ONLY)
JUMPER J1001
Used to reduce the ED2.0 board power consumption from 75 to 33 watts. Capacitor charging
time will increase in the 33 watt setting.
SWITCH POSITION OFF ON
1 INPUT 1 FAST (2 ms) INPUT 1 SLOW (10 ms)
2 INPUT 2 FAST (2 ms) INPUT 2 SLOW (10 ms)
3 INPUT 3 FAST (2 ms) INPUT 3 SLOW (10 ms)
4 INPUT 3 USED AS INPUT 3 USED AS
AUXILIARY INPUT AUXILIARY INPUT
