ABB R-MAG Series User Manual

ILLUSTRATION 6 – READY, NOT READY INDICATORS
CIRCUIT BREAKER POSITION
CONDITION CLOSE OPEN
Capacitor Energy sufficient Ready LED: on Ready LED: on
For O-CO operations Ready contact: closed Ready contact: closed
Not ready contact: opened Not ready contact: opened
Capacitor Energy sufficient for Ready LED: blinking Ready LED: blinking
CO operations Ready contact: closed Ready contact: closed
Not ready contact: opened Not ready contact: opened
Capacitor Energy sufficient for Ready LED: blinking Ready LED: off
O operations Ready contact: closed Ready contact: opened
Not ready contact: opened Not ready contact: closed
Capacitor Energy insufficient for Ready LED: off Ready LED: off
any operations Ready contact: opened Ready contact: opened
Not ready contact: closed Not ready contact: closed
Close Coil continuity not right Ready LED: blinking Ready LED: off
Ready contact: closed Ready contact: opened
Not ready contact: opened Not ready contact: closed
Open Coil continuity not right Ready LED: off Ready LED: off
Ready contact: opened Ready contact: opened
Not ready contact: closed Not ready contact: closed
Page 38
