TABLE 4-1. SETTING DISPLAY (SHEET4 OF 4)
Setting Function Display Value Displayed (INCOM®)
Front Panel
Directional overcurrent ground
backup time curve family GB Type Disabled (OUT) / CO-2 / CO-5 /
(With Time Delay or Inst. Reset) CO-6 / CO-7 / CO-8 / CO-9 / CO11
(each w/Reset or Inst.)
Ground backup pick-up GBPickup 0.5 - 4.0 amps
Ground backup time curves
within family GBTCurve 1 - 63
Choice of directional or non
directional ground backup GB Dir Yes / No
Close into fault trip CIF Trip CIF TRIP
CIF TRIP W/DELAY
NO CIF TRIP
Load loss trip LL Trip Yes / No / FDOG
Loss of potential block LOP Blk Yes / No
Loss of current block LOI Blk Yes / No
Trip alarm seal-in Trip Alm Seal-in (YES) or No Seal-in (NO)
Remote setting change enable Rem. Set Remote Allowed (YES) or
No Remote (NO)
Real time clock set Set Time Yes / No
1. Set year Year 1980 - 2079
2. Set month Month 1 - 12
3. Set day Day 1 - 31
4. Set weekday Weekday Sunday (SUN) thru Saturday (SAT)
5. Set hour Hour 0 - 23
6. Set minute Minute 0 - 59
To Next Page
