ABB REL301 - Reclosing Initiation Mode Programming

I.L. 40-386.3
(10/94) 3-15
TABLE 3-2. RECLOSING INITIATION MODE PROGRAMMING
RI Type Type Of Fault Reclosing Initiation Mode
OFF All Faults No reclosing initiation
1PR φG RI-1, RI-2 contacts close;
All Other Faults no reclosing
2PR φG, φφ RI-1, RI-2 contacts close;
3φ Faults no reclosing
3PR All Faults RI-1, RI-2 contacts close
TABLE 3-1. TRIP TIME CONSTANTS FOR CURVES
CURVE #
T
0K C P R
C02 111.99 735.00 0.675 1 501
C05 8196.67 13768.94 1.13 1 22705
C06 784.52 671.01 1.19 1 1475
C07 524.84 3120.56 0.8 1 2491
C08 477.84 4122.08 1.27 1 9200
C09 310.01 2756.06 1.35 1 9342
C011 110 17640.00 0.5 2 8875
