TABLE 4-1. SETTING DISPLAY (SHEET 3 OF 4)
(continued)
Setting Function Display Value Displayed (INCOM®)
Front Panel
Zone2 Ground Timer
– Timer Type T2G Type Blocked (DISAB) / Definite Time
(DEFTM) / Torque Control (TORQ)
– Definite Time T2GTime 0.10 - 2.99 sec
– Torque Control CO Curve T2GCV CO-2/CO-5/CO-6/ CO-7/CO-8/
(with Time Delay or Inst. Reset) CO-9/ CO-11 Reset or Instantaneous
– Torque Control Pickup T2G Pkup (T2GPU 0.5 - 10.0 amps
– Torque Control Time Curve T2G TC (T2GTC) 1 - 63
Zone3 phase unit Zone3 ø Disabled (OUT) / 0.01 -50.00Ω
Zone3 phase timer T3 ø Blocked (BLK) / 0.10 - 9.99 sec
Zone3 ground unit Zone3 G Disabled (OUT) / 0.01 - 50.00 Ω
Zone3 ground reverse reach Zone3G R Disable (OUT) / 0.01 - 50.00Ω
Zone3 ground timer T3 G Blocked (BLK) / 0.10 - 9.99 sec
Zone3 direction Zone3 Forward dir. (FWD)
Reverse dir. (REV)
Pos. seq. line impedance angle Ang Pos. 10 - 90 degrees
Zero seq. line impedance angle Ang Zero 10 - 90 degrees
Z0L / Z1L Z0L/Z1L 0.1 - 10.0
Low voltage unit Low V 40 - 60 Volts (rms)
Overcurrent units:
– Low set phase Low Iø 0.5 - 10.0 amps
– Medium set phase IM 0.5 - 10.0 amps
– Low set ground 3I0s 0.5 - 10.0 amps
– Medium set ground 3I0m 0.5 - 10.0 amps
– High set phase Inst. ø Disabled (OUT) / 2 - 150 amps
– High set ground Inst. G Disabled (OUT) / 2- 150 amps
Out-of-step block OS Block Yes / No
OSB override timer OSOT 400 - 4000 msec
OSB inner blinder OS Inner 1.0 - 15.0Ω
OSB outer blinder OS Outer 3.0 - 15.0Ω
Directional Unit Polarization Dir Type Zero sequence (ZSEQ)
Negative sequ (NSEQ)
Dual Polariz (DUAL)
