I.L. 40-386.3
(10/94) 4-17
TABLE 4-1. SETTING DISPLAY (SHEET 2 OF 4)
Setting Function Display Value Displayed (INCOM®)
Front Panel
System Type Selection SystType Non Pilot (3ZNP)
Zone1 Extension (Z1E)
POTT (POTT)
PUTT (PUTT)
Blocking (BLK)
Forward directional ground timer FDOGTime Blocked (BLK) / 0 - 15 cycles
Weakfeed enable Weakfeed Yes / No
3-Terminal line application 3-Term. Yes / No
Blocking system channel
coordination timer Blk Time 0 - 98 msec
Pilot phase setting Pilot ø Disabled (OUT) / 0.01 - 50.00Ω
Pilot ground setting PilotG Disabled (OUT) / 0.01 - 50.00Ω
Pilot ground reverse reach PilotG R Disabled (OUT) / 0.01 - 50.00Ω
Zone1 phase unit Zone1 ø Disabled (OUT) / 0.01 - 50.00Ω
Zone1 ground unit Zone1G Disabled (OUT) / 0.01 - 50.00Ω
Zone1 ground reverse reach Zone1G R Disabled (OUT) / 0.01 - 50.000Ω
Zone1 delay trip timer T1 Timer 0 - 15 cycles
Zone2 phase unit Zone2 ø Disabled (OUT) / 0.01 - 50.00Ω
Zone2 Phase Timer
– Timer Type T2ø Type Blocked (DISAB) / Definite Time
(DEFTM) / Torque Control (TORQ)
– Definite Time T2ø Time 0.10 - 2.99 sec
– Torque Control CO Curve T2ø CV CO-2/CO-5/CO-6/ CO-7/CO-8/
(with Time Delay or Inst. Reset) CO-9/ CO-11 (each w/Reset or Inst)
– Torque Control Pickup T2ø Pkup (T2PPU) 0.5 - 10.0 amps
– Torque Control Time Curve T2ø TC (T2PTC) 1 - 63
Zone2 ground unit Zone2 G Disabled (OUT) / 0.01 - 50.00Ω
Zone2 ground reverse reach Zone2G R Disabled (OUT) / 0.01 - 50.000Ω
(continued)
