Setting Function Display Value Displayed (INCOM®)
Front Panel
Software Version Version numerical
Oscillographic data
Initiation Osc Data Trip (TRIP) / Zone2 (Z2TR) /
Zone2, Zone3 (Z2Z3) /
∆V or ∆I (∆V∆I)
Fault data initiation Flt Data Trip (TRIP)/ Zone2 (Z2TR)/
Zone2, Zone3 (Z2Z3)
CT ratio CT Ratio 10 – 5000
PT ratio VT Ratio 30 – 7000
Rated frequency Freq. 60 / 50 Hz
CT secondary rating CT Type 5 / 1 amps
Read out I and V in Primary
or secondary units Read Out Primary Units / Secondary Units
Reactance for fault location X / Dist 0.300 – 1.500 Ω/mile or /km
dependent on “DistUnit” setting
Fault location units DistUnit Miles / Kilometers (MI /KM)
Reclosing Mode RI Type No RI (OFF)
φG RI (1PR)
φφ, φG RI (2PR)
3φ, φφ, φφG, φG RI (3PR)
High Speed RI Fast RI None (NO)
Z1 / Inst I (Z1-II)
Pilot (PLT)
Pilot/Z1/Inst I (ALL)
RI on Zone2 trip Zone2 RI Yes / No
RI on Zone3 trip Zone3 RI Yes / No
Breaker failure reclose block RemBF RB Yes / No
Remote pilot control Pilot Yes / No
TABLE 4-1. SETTING DISPLAY (SHEET 1 OF 4)
