TABLE 4-3. TARGET (FAULT DATA) DISPLAY (SHEET 2 OF 2)
Front Panel RCP
Information Display Display
Receiver 1 Rx Ch1 (RX1) Yes / No
Receiver 2 Rx Ch2 (RX2) Yes / No
Weakfeed trip Weakfeed (WFT) Yes / No
Phase A fault voltage VAG Flt (VPA) magnitude (Volts) and angle (°)
Phase B fault voltage VBG Flt (VPB) magnitude (Volts) and angle (°)
Phase C fault voltage VCB Flt (VPC) magnitude (Volts) and angle (°)
3V0 fault voltage 3V0 Flt (3V0) magnitude (volts) and angle (°)
Phase A fault current IA Flt (IPA) magnitude (Amps) and angle (°)
Phase B fault current IB Flt (IPB) magnitude (Amps) and angle (°)
Phase C fault current IC Flt (IPC) magnitude (Amps) and angle (°)
IP fault current IP Flt (IP) magnitude (Amps) and angle (°)
Date of fault Date Flt (DATE) Month/day and year
Time of fault Time Flt (TIME) Hours, minutes, seconds and
fractions
NOTE: On front panel display, all Yes or No information displayed when the
answer is YES
