ABB Relion REF615R User Manual

1MRS240173-IB B Section 5
4x Registers
REF615R 37
DPU2000R Modbus Point List Mitigation Manual
5.1.5 RMS Peak Demand Current/Real, Reactive Power Values and
Time Stamps Block
REF615R maps all the registers in this block in the same way as in DPU2000R except
some scaling factor differences. Please see Section 5.1.3 on how to change the default
scaling factors.
Table 14: Mitigation of Modbus mappings for peak demand current/real, reactive power values and time
stamps blocks
DPU2000R
register
addr.
DPU2000R description Scale
REF615R
register
addr.
Scale IEC61850 path
Comments on
REF615R Modbus
points mapping
40513 Peak Demand Current-A 1 40513 100 LD0.CMSTA1.MaxAmpsA.mag.f reading per unit
value by default
40514 Peak Demand Current-A Year,
Month
40514 LD0.CMSTA1.MaxAmpsA.t Year, Month
40515 Peak Demand Current-A Day,
Hour
40515 Day, Hour
40516 Peak Demand Current-A Minute 40516 Minute
40517 Peak Demand Current-B 1 40517 100 LD0.CMSTA1.MaxAmpsB.mag.f reading per unit
value by default
40518 Peak Demand Current-B Year,
Month
40518 LD0.CMSTA1.MaxAmpsB.t Year, Month
40519 Peak Demand Current-B Day,
Hour
40519 Day, Hour
40520 Peak Demand Current-B Minute 40520 Minute
40521 Peak Demand Current-C 1 40521 100 LD0.CMSTA1.MaxAmpsC.mag.f reading per unit
value by default
40522 Peak Demand Current-C Year,
Month
40522 LD0.CMSTA1.MaxAmpsC.t Year, Month
40523 Peak Demand Current-C Day,
Hour
40523 Day, Hour
40524 Peak Demand Current-C Minute 40524 Minute
40525 Peak Demand Current-N 1 40525 100 LD0.RESCMSTA1.MaxAmps.mag.f reading per unit
value by default
40526 Peak Demand Current-N Year,
Month
40526 LD0.RESCMSTA1.MaxAmps.t Year, Month
40527 Peak Demand Current-N Day,
Hour
40527 Day, Hour
40528 Peak Demand Current-N Minute 40528 Minute
40529 Peak Demand KWatts-A 1 40529 1 LD0.SPEMSTA1.MaxWPhsA.mag.f
40531 Peak Demand KWatts-A Year,
Month
40531 LD0.SPEMSTA1.MaxWPhsA.t Year, Month
40532 Peak Demand KWatts-A Day,
Hour
40532 Day, Hour
40533 Peak Demand KWatts-A Minute 40533 Minute
40534 Peak Demand KWatts-B 1 40534 1 LD0.SPEMSTA1.MaxWPhsB.mag.f
40536 Peak Demand KWatts-B Year,
Month
40536 LD0.SPEMSTA1.MaxWPhsB.t Year, Month
40537 Peak Demand KWatts-B Day,
Hour
40537 Day, Hour
