Section 3 1MAC254287-MB B
DNP3 protocol implementation
38 REM615 ANSI
Point List Manual
Table 92: Device profile document
DNP3 device profile document
Vendor name: ABB Inc.
Device name: REF615
Highest DNP level supported: Device function:
For requests: Level 2+ ○ Master
For responses: Level 2+ ● Slave
Notable objects, functions, and/or qualifiers supported in addition to the highest DNP levels supported (the complete list is described in the
attached table):
For static (non-change-event) object requests, request qualifier codes 07 and 08 (limited quantity), and 17 and 28 (index) are supported. Static
object requests sent with qualifiers 07, or 08, will be responded with qualifiers 00 or 01.
16-bit and 32-bit Analog Change Events with Time may be requested.
Maximum data link frame size (octets): Maximum application fragment size (octets):
Transmitted: 292 Transmitted: Configurable (256...2048)
Received: 292 Received: 2048
Maximum data link re-tries: Maximum application layer re-tries:
○ None ● None
○ Fixed ○ Configurable
● Configurable (0...65535)
Requires data link layer confirmation:
○ Never
○Always
○ Sometimes
● Configurable as: "Never", "Only for multi-frame messages", or "Always"
Requires application layer confirmation:
○Never
○Always
○ When reporting event data (slave devices only)
○ When sending multi-fragment responses (slave devices only)
○ Sometimes
● Configurable as: "Only when reporting event data", or "When reporting event data or multi-fragment messages"
Timeouts while waiting for:
Data link
confirm:
○ None ○ Fixed at ____ ○ Variable ● Configurable
Complete
appl.
fragment:
● None ○ Fixed at ____ ○ Variable ○ Configurable
Application
confirm:
○ None ○ Fixed at ____ ○ Variable ● Configurable
Complete
appl.
response:
● None ○ Fixed at ____ ○ Variable ○ Configurable
Others: Select/Operate Arm Timeout, not configurable; fixed at 10s, regardless of select timeout in the HMI.
Need time interval, configurable
Unsolicited notification delay, configurable
Unsolicited response retry delay, configurable
Unsolicited offline Interval, configurable
Sends/Executes Control Operations:
