1MRS751802-MUM

REX 521

Protection Relay

Technical Reference Manual, Standard Configurations

3.3.3. Standard configuration H03

3.3.3.1. Features

• Three-phase non-directional overcurrent protection with three stages

• Three-phase transformer inrush and motor start-up current detector

• Directional earth fault protection with three stages

• Phase discontinuity protection for three phases

• Three-phase thermal protection for cable

• Synchro-check/voltage-check function with one stage

• Supervision function for energizing current input circuit

• Supervision function for energizing voltage input circuit

• Current waveform distortion measurement

• Voltage waveform distortion measurement

• Three-phase current measurement

• Neutral current measurement

• Three phase voltage measurements

• Residual voltage measurement

• System frequency measurement

• Three-phase power and energy measurement

• Calculation of the accumulated electric breaker wear of the circuit breaker (CB)

• Transient disturbance recorder

• Trip-circuit supervision

• Delayed trip output for the circuit-breaker failure protection (CBFP) function

• Automatic reclosing 1…5 shots

• Circuit breaker control with indication

• Lockout function

• Object indication

• Logic control position selector

• User-configurable I/Os

•Interlocking

• User-configurable alarm LEDs

1. Only in Sensor version.
