Table 233. Functions included in the relay, continued
Function IEC 61850 IEC 60617 ANSI
Logging functions
Disturbance recorder (common functionality) RDRE DR DFR
Disturbance recorder, analog channels 1...12 A1RADR A1RADR A1RADR
Disturbance recorder, analog channels 13...24 A2RADR A2RADR A2RADR
Disturbance recorder, binary channels 1...32 B1RBDR B1RBDR B1RBDR
Disturbance recorder, binary channels 33...64 B2RBDR B2RBDR B2RBDR
Fault recorder FLTRFRC FAULTREC FR
Other functionality
Parameter setting groups PROTECTION PROTECTION PROTECTION
Time master supervision GNRLLTMS GNRLLTMS GNRLLTMS
Serial port supervision SERLCCH SERLCCH SERLCCH
IEC 61850-1 MMS MMSLPRT MMSLPRT MMSLPRT
IEC 61850-1 GOOSE GSELPRT GSELPRT GSELPRT
IEC 60870-5-103 protocol I3CLPRT I3CLPRT I3CLPRT
DNP3 protocol DNPLPRT DNPLPRT DNPLPRT
Modbus protocol MBSLPRT MBSLPRT MBSLPRT
OR gate with two inputs OR OR OR
OR gate with six inputs OR6 OR6 OR6
OR gate with twenty inputs OR20 OR20 OR20
AND gate with two inputs AND AND AND
AND gate with six inputs AND6 AND6 AND6
AND gate with twenty inputs AND20 AND20 AND20
XOR gate with two inputs XOR XOR XOR
NOT gate NOT NOT NOT
Real maximum value selector MAX3R MAX3R MAX3R
Real minimum value selector MIN3R MIN3R MIN3R
Rising edge detector R_TRIG R_TRIG R_TRIG
Falling edge detector F_TRIG F_TRIG F_TRIG
Real switch selector SWITCHR SWITCHR SWITCHR
Integer 32-bit switch selector SWITCHI32 SWITCHI32 SWITCHI32
SR flip-flop, volatile SR SR SR
RS flip-flop, volatile RS RS RS
Minimum pulse timer, two channels TPGAPC TP 62TP
Minimum pulse timer second resolution, two channels TPSGAPC TPS 62TPS
Minimum pulse timer minutes resolution, two channels TPMGAPC TPM 62TPM
Pulse counter for energy measurement PCGAPC PCGAPC PCGAPC
Pulse timer, eight channels PTGAPC PT 62PT
Time delay off, eight channels TOFGAPC TOF 62TOF
1MRS759144 A
