Table 233. Functions included in the relay, continued
Function IEC 61850 IEC 60617 ANSI
Time delay on, eight channels TONGAPC TON 62TON
Daily timer DTMGAPC DTM DTM
Calendar function CALGAPC CAL CAL
SR flip-flop, eight channels, nonvolatile SRGAPC SR SR
Boolean value event creation MVGAPC MV MV
Integer value event creation MVI4GAPC MVI4 MVI4
Analog value event creation with scaling SCA4GAPC SCA4 SCA4
Generic control points SPCGAPC SPC SPCG
Generic up-down counter UDFCNT UDCNT UDCNT
Local/Remote control CONTROL CONTROL CONTROL
External HMI wake-up EIHMI EIHMI EIHMI
Real addition ADDR ADDR ADDR
Real subtraction SUBR SUBR SUBR
Real multiplication MULR MULR MULR
Real division DIVR DIVR DIVR
Real equal comparator EQR EQR EQR
Real not equal comparator NER NER NER
Real greater than or equal comparator GER GER GER
Real less than or equal comparator LER LER LER
Voltage switch VMSWI VSWI VSWI
Current sum CMSUM CSUM CSUM
Current switch CMSWI CMSWI CMSWI
Phase current preprocessing ILTCTR ILTCTR ILTCTR
Residual current preprocessing RESTCTR RESTCTR RESTCTR
Phase and residual voltage preprocessing UTVTR UTVTR UTVTR
SMV stream receiver (IEC 61850-9-2LE) SMVRCV SMVRCV SMVRCV
SMV stream sender (IEC 61850-9-2LE) SMVSENDER SMVSENDER SMVSENDER
Redundant Ethernet channel supervison RCHLCCH RCHLCCH RCHLCCH
Ethernet channel supervision SCHLCCH SCHLCCH SCHLCCH
HMI Ethernet channel supervision HMILCCH HMILCCH HMILCCH
Received GOOSE binary information GOOSERCV_BIN GOOSERCV_BIN GOOSERCV_BIN
Received GOOSE double binary information GOOSERCV_DP GOOSERCV_DP GOOSERCV_DP
Received GOOSE measured value information GOOSERCV_MV GOOSERCV_MV GOOSERCV_MV
Received GOOSE 8b-it integer value information GOOSERCV_INT8 GOOSERCV_INT8 GOOSERCV_INT8
Received GOOSE 32-bit integer value information GOOSERCV_INT32 GOOSERCV_INT32 GOOSERCV_INT32
Received GOOSE interlocking information GOOSERCV_INTL GOOSERCV_INTL GOOSERCV_INTL
Received GOOSE measured value (phasor)
information
GOOSERCV_CMV GOOSERCV_CMV GOOSERCV_CMV
1MRS759144 A
