ABB | SACE Emax 2
8 | © 2019 ABB | 1SDH001000R0002 - ECN000109166 - Rev. D Management operations | 1 - Transport and checking on receipt
Identification of packaging
Examine the state of the packaging and check that:
• The data on the packaging plate match the data of the order.
• The box is intact and perfectly closed.
SACE EMAX E2.2 N 1600
VERSION
FIXED
POL 4
TERMINALS
REAR HORIZONTAL TERMINALS
WITH ASSEMBLED ACCESSORIES
YO 24V AC-DC
CODE
A.B.
FB.NR.
80156446401183
803 1004035
Designed by ABB SACE Division
1SDA055987R1
1130055880 004100
BB44005099
1
2
4
5
3
6
Figure 3
Pos. Description
1 Short description of the circuit-breaker
2 Description of accessories
3 Commercial code
4 Confirmation number and location
5 Circuit-breaker serial number
6 Features of the circuit-breaker
Packaging checks
Examine the state of the material received and verify that:
• The circuit-breaker or the fixed part are consistent with the order.
• The circuit-breaker or the fixed part are completely intact.
IMPORTANT:
• If the material is to be stored, check it beforehand. For opening the packaging,
follow the procedures outlined in the section "Unpacking and handling - opening the
packages" on page 10
• In the case of any inconsistencies, report them within five days of reception. See the
paragraph "Damage and Discrepancy Report" in this chapter.
Damage and Discrepancy
Report
If there is any damage to the packaging upon receipt and / or inconsistencies between order and product
identification label or product please contact ABB. Damage to the packaging must be reported no later than
seven days from receipt of the material.
NOTE: The notification must indicate the Packing List number.
