Management operations
1 - Transport and checking on receipt
Introduction
The SACE Emax 2 circuit-breakers, on account of their weight, require special attention during transport and
handling.
They are distributed with following packages:
• single package for fixed circuit-breaker
• two packages for withdrawable circuit-breakers (one package for the fixed part and one for the mobile part).
WARNING! comply with the following instructions during each transport phase:
• The movable part of the circuit-breaker must be removed from the switchgear and/or
from the relative fixed part even if this latter is not installed in the switchgear.
• The circuit-breaker must be in the open position.
• The circuit-breaker must be protected and fastened in its original packing.
• The closing springs of the circuit-breaker must be completely discharged.
Weight of the circuit-breakers
with packaging
The following table specifies the weights of the circuit-breakers with packaging:
Fixed
Moving part of
withdrawable device
Fixed part of
withdrawable device
III IV Fs III IV Fs III IV Fs
E2.2
46 Kg /
101 lbs
58 Kg /
128 lbs
53 Kg /
117 lbs
60 Kg /
132 lbs
41 Kg /
90 lbs
49 Kg /
108 lbs
E4.2
63 Kg /
139 lbs
77 Kg /
170 lbs
67 Kg /
148 lbs
81 Kg /
179 lbs
57 Kg /
126 lbs
69 Kg /
152 lbs
E6.2
118 Kg /
260 lbs
134 Kg /
295 lbs
151 Kg /
333 lbs
129 Kg /
258 lbs
143 Kg /
315 lbs
159 Kg /
350 lbs
96 Kg /
212 lbs
109 Kg /
240 lbs
123 Kg /
271 lbs
E2.2-A
50 Kg /
110 lbs
63 Kg /
139 lbs
59 Kg /
130 lbs
68 Kg /
150 lbs
39 Kg /
86 lbs
46 Kg /
101 lbs
E4.2-A
66 Kg /
154 lbs
81 Kg /
179 lbs
75 Kg /
165 lbs
91 Kg /
201 lbs
52 Kg /
115 lbs
63 Kg /
139 lbs
E6.2-A
126 Kg /
278 lbs
143 Kg /
315 lbs
159 Kg /
351 lbs
147 Kg /
324 lbs
163 Kg /
359 lbs
180 Kg /
397 lbs
88 Kg /
194 lbs
100 Kg /
220 lbs
110 Kg /
243 lbs
NOTE:
• weights are indicated with reference to the basic circuit-breakers including protection trip unit
and its sensors, without terminals and without accessories.
• the weights of the fixed part of withdrawable circuit-breakers refer to the version with horizontal
rear terminals.
Transport of the packaged
circuit-breaker
Consult the table "Weight of the circuit-breakers with packaging" before proceeding with the transport.
WARNING! Improper lifting can result in death, serious injury to persons and damage
to the equipment. Never lift a circuit-breaker and / or a fixed part above other people.
IMPORTANT: The trained personnel in charge of handling and lifting must use
appropriate safety equipment.
