22
In the SPACOM system the event codes
E52…E54 are formed by the station level con-
trol data communicator.
1) Event E9, output activation inhibited, is given
when the operation is inhibited by the inter-
locking program or by an input channel
4…13.
2) Event E10, output activation fault, is given
if the status of the controlled object does not
change during the time of the output pulse.
3) Event E11, attempt to activate an output
without an open/close selection, is given when
a secured control is made in a situation where
the state of alert has not been defined.
The control module has the following event codes:
Channel Code Event Number re- Default value
presenting of event factor
event
0 E1 Key switch to LOCAL position 1 1
0 E2 Key switch to REMOTE position 2 1
0 E3 Output test switch SG1/1 ON 4 0
0 E4 Output test switch SG1/1 OFF 8 0
V155 = 3
1…3 E1 Change in status; xx -> 10 (open) 1 1
1…3 E2 Change in status; xx -> 01 (closed) 2 1
1…3 E3 Change in status; xx ->11 (undefined) 4 0
1…3 E4 Change in status; xx ->00 (undefined) 8 0
1…3 E5 OPEN output activated 16 1
1…3 E6 OPEN output reset 32 0
1…3 E7 CLOSE output activated 64 1
1…3 E8 CLOSE output reset 128 0
1…3 E9 Output activation inhibited 1) 256 1
1…3 E10 Output activation fault 2) 512 1
1…3 E11 Trying to activate an output without
open/close selection 3) 1024 1
V155 = 1875
4…13 E1 Input channel activated 1 1
4…13 E2 Input channel reset 2 1
4…13 E3 SIGNAL1…3 output activated 4 0
4…13 E4 SIGNAL1…3 output reset 8 0
V155 =3
0 E50 Restarting * -
0 E51 Overflow of event register * -
0 E52 Temporary disturbance in data -
communication
0 E53 No response from the module * -
over the data communication
0 E54 The module responds again * -
over the data communication
0 not included in the event reporting
1 included in the event reporting
* no code number
- cannot be programmed
