23
If all the parameters are programmed at the same
time the following instructions should be used
when changing between program and run mode
and when storing the parameters.
As a default the parameters related to interlock-
ing and configuration have the following values:
S100 = 1
Default configuration and interlocking 1
S198 = 1
The interlocking program is in run mode
S199 = 1
Interlockings are in use
The following examples illustrate the program-
ming.
Example 18: Select another configuration and
interlocking than default 1.
>99WS198:0:XX
; Change into program mode
>99WS100:2:XX
; Select the default 2
>99WS198:1:XX
; Change into run mode
.
; Change other parameters
.
.
>99WV151:1:XX
; Store the programmed parameters
Example 19: Select a user defined configuration
and interlocking.
>99WS198:0:XX
; Change into program mode
>99WS100:0:XX
; Change into freely programmable mode
>99WS101:…
; Configuration commands
.
.
.
>99WM200:…
; Interlocking program
.
.
.
>99WS198:1:XX
; Change into run mode
.
; Change other parameters
.
.
>99WV151:1:XX
; Store the programmed parameters
Programming
quick reference
