28
Data Channel Code Data Values
direction
Type designation of the module 0 F R SPTO 1D2
Reading of event register 0 L R Time, channel number
and event code
Re-reading of event register 0 B R Time, channel number
and event code
Reading of module status 0 C R 0 = normal state
information 1 = module been subject
to automatic reset
2 = overflow of event
register
3 = events 1 and 2
together
Resetting of module status 0 C W 0 = resetting
information
Time reading and setting 0 T RW 0.000…59.999 s
R = Data which can be read from the unit
W = Data which can be written to the unit
(e) = Data which has to be stored into EEPROM (V151) after having been changed
The data transfer codes L, B, C and T have been
reserved for the event data transfer between the
module and the station level data communica-
tor.
The event register can be read by the L com-
mand only once. Should a fault occur e.g. in the
data transmission, it is possible, by using the B
command, to re-read the contents of the event
register once read by means of the L command.
When required, the B command can be re-
peated.
