Specifications
WBPEEUI240774A0 1 - 9
Magnetic and electromagnetic
fields
Power frequency magnetic
field (IEC 61000-4-8, EN
61000-4-8)
Pulse magnetic field (IEC
61000-4-9, EN 61000-4-9)
Damped oscillatory magnetic
field, 0.1 MHz and 1 MHz (IEC
61000-4-10, EN 61000-4-10)
Radiated radio-frequency
electromagnetic field, 80 MHz
to 1GHz (IEC 61000-4-3)
Radiated radio-frequency
field, 900 ±5 MHz (ENV
50204)
Radio-frequency common
mode, amplitude modulated,
0.15 MHz to 80 MHz (IEC
61000-4-6)
Continuous: 30 A
RMS
/m
Short duration: 300 A
RMS
/m
Peak value: 300 A/m
Peak value: 30 A/m
Unmodulated RMS: 10 V/m
Amplitude modulated: 80% AM (1 kHz)
Unmodulated RMS: 10 V/m
Pulse modulated: Duty cycle 50%, Rep. cycle 200 Hz
Unmodulated RMS: 10 V
Amplitude modulated: 80% AM (1 kHz)
Source impedance: 150 !
Emission test RF radiated
fields, 30 MHz to 1000 MHz
(EN 55011)
Class A
Mounting Occupies a single slot in a standard module mounting unit.
Environment
Ambient temperature
Relative humidity
Altitude
Air quality
0° to 70° C (32° to 158° F)
5% to 95% up to 55° C (131° F) (noncondensing)
5% to 45% at 70° C (158° F) (noncondensing)
Pollution degree: 1
Sea level to 3 km (1.86 miles)
Noncorrosive
Shipping weight 1.146 kg (2.5 lb)
Container size 27.94 cm x 35.56 cm x 5.54 cm (11 in. x 14 in. x 3 in.)
Table 1-4. S pec ification s
(continued)
Property Characteristic/Value
