Operation Manual / TPL85-B14/-B15/-B16
-term turbocharger shut-down
© Copyright 2016 ABB. All rights reserved.
May 2016 HZTL2491_EN Revision B
Remove filter silencer and internal part of compressor casing complete
with wall insert and diffuser. (See chapter
Disassembly and assembly.)
Fix partition wall using press-off tools (90920) and screws.
Fit locking device (90020) in accordance with following illustrations.
Make sure the intermediate rings, the spacer ring and the adapter ring are
fitted correctly.
All parts must be kept clean and free from grease.
74027 Hexagon nut
90020 Locking device
90920 Press-off tool with screw
94001 / 94002 Intermediate ring
94003 Locking flange
94004 Adapter ring
94006 / 94008 Hexagon-head screw
94031 Spacer ring
94032 Washer
The locking flange (94003) must be fitted to the compressor wheel
(94008), tightened according to the
Table of tightening
torques
94006 M12
75
94008 M12
60
Table of tightening tor-
ques [Nm]
