ABB TPL-B Series User Manual

Operation Manual / TPL85-B14/-B15/-B16
Spare parts
12
View of cartridge group with part
numbers
12.3
Page 131
© Copyright 2016 ABB. All rights reserved.
May 2016 HZTL2491_EN Revision B
Part number
Description
21000 Shaft
25000
Compressor wheel
25008 Threaded stud
25009
Ring nut
32001 Thrust bearing
32101
Radial bearing at compressor end
32102 Radial bearing at turbine end
32104
Auxiliary bearing
32105 Floating disc
32106
Axial bearing
42001 Bearing casing
42002
Hood
42011 O-ring
42012 (in customer spare parts set)
O-ring
42015 Sealing cover
42041 (in customer spare parts set)
Gasket
42045 (in customer spare parts set) Gasket
42059 (in customer spare parts set)
Hexagon-head screw
42064 (in customer spare parts set) Hexagon-head screw
42295
Non-return flap
43001 Partition wall
43005
O-ring
86505 Speed sensor
86506 (in customer spare parts set)
O-ring
