ABB TPL-B Series User Manual

Operation Manual / TPL85-B14/-B15/-B16
Start
-up
3
Oil supply
3.1
Page 30
© Copyright 2016 ABB. All rights reserved.
May 2016 HZTL2491_EN Revision B
Oil pressure
The oil pressure in front of the turbocharger must be maintained precisely
to ensure trouble-free operation.
The permissible oil pressures are specified in the following tables and de-
pend on the type of lubrication (engine lubrication or separate lubricating
system).
Kinetic viscosity 45 … 170 cST
Oil pressure [bar]
Impermissible oil pressure range ->
emergency shutdown
(without time lag)
0.0 … 0.6
Temporarily permissible (< 1h) -> alarm
0.6 … 0.8
Permissible oil pressure range for normal operation
0.8 … 2.5
Permissible oil pressure range during engine warm-up
phase
0.8 … 4.0
Kinetic viscosity 12 … 170 cSt
Oil pressure [bar]
Impermissible oil pressure range ->
emergency shutdown
(without time lag)
0.0 … 0.9
Temporarily permissible (< 1h) -> alarm
0.9 … 1.1
Permissible oil pressure range for normal operation
1.1 … 2.5
Permissible oil pressure range during engine warm-
up phase
1.1 … 4.0
NOTICE
If a separate lubricating system has been designed for operation in the
viscosity range of the engine lubrication system, i.e. 45 ... 170 cSt, then
the
oil pressure limits according to the engine lubrication information
may be applied for such a system.
Engine lubrication
Separate lubricating sys-
tem
