Operation Manual / TPS44-F.. - TPS61-F..
12 Spare parts / 12.3 View of cartridge group showing part numbers
© Copyright 2020 . All rights reserved. HZTL2412_EN Rev.G March 2020
Part number Description
21000 Shaft
21002 Piston ring
25000 Compressor wheel
32101 Plain bearing bush
32103 Locking ring
32105 Thrust ring
32106 Thrust bearing
32108 Piston ring
32109 Sealing disc
32110 Bearing flange
32111 Auxiliary bearing
32112 Bearing flange
32113 Socket screw
32114 Socket screw
32221 Bearing cover
32222 O-ring
42001 Bearing casing
42002 Socket screw
42008 (in customer spare part set) Socket screw
43001 Partition wall
43012* Metal C-ring
* depends on the turbocharger specification.
