24 TTF200 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF200-EN REV. A
7.4.1 Parameter descriptions
DTM menu path, parameters Description
<Device> / <Extras>
<Write Protection> Activates write protection for the entire device
— Yes: locked
— No: unlocked
— Enter password: 0110
<Device reset> Configuration data is reset to factory settings (see ‘Factory settings’ on page 26 )
<Factory reset> Configuration data is reset to factory settings (see ‘Factory settings’ on page 26 ).
The adjustment data Trim high and low and DAC adjustment values are also reset to factory settings.
— Yes / OK
<Device> / <Configuration>
<Sensor / Sensor type> Selects sensor type:
— Pt100 (IEC751)
— Pt1000 (IEC751)
— Thermocouple type K (IEC584)
— Thermocouple type B (IEC584)
— Thermocouple type C (ASTME988)
— Thermocouple type D (ASTME988)
— Thermocouple type E (IEC584)
— Thermocouple type J (IEC584)
— Thermocouple type N (IEC584)
— Thermocouple type R (IEC584)
— Thermocouple type S (IEC584)
— Thermocouple type T (IEC584)
— Thermocouple type L (DIN43710)
— Thermocouple type U (DIN43710)
— Thermovoltage –125 … 125mV
— Thermovoltage –125 … 1100mV
— Resistance 0 …. 500 Ω
— Resistance 0 …. 5000 Ω
— Pt10 (IEC751)
— Pt50 (IEC751)
— Pt200 (IEC751)
— Pt500 (IEC751)
— Pt10 (JIS1604)
— Pt50 (JIS1604)
— Pt100 (JIS1604)
— Pt200 (JIS1604)
— Pt10 (IMIL24388)
— Pt50 (IMIL24388)
— Pt100 (MIL24388)
— Pt200 (MIL24388)
— Pt1000 (MIL24388)
— Ni50 (DIN43760)
— Ni100 (DIN43760)
— Ni120 (DIN43760)
— Ni1000 (DIN43760)
— Cu10 (OIML R 84), a=4270
— Cu100 (OIML R 84), a=4270
