DIAG. NO.
Cause Remedy
Electronics F 1 Device defective Replace the device
Electronics S 2 Ambient temperature overshot / undershot Check environment; reposition measuring point
if required
Electronics F 3 EEPROM defective Replace the device
Electronics M 4 Electronics overload Factory reset
Electronics F 5 Memory error Factory reset
Electronics I 7 LCD indicator connected Status info; not an error
Installation / Configuration I 8 Device write-protected Status info; not an error
Electronics I 9 EEPROM busy Status info; not an error
Electronics F 12 Sensor input defective (communication) Replace the device
Electronics F 13 Sensor input defective (error) Replace the device
Electronics F 14 Sensor input defective (ADC error) Replace the device
Installation / Configuration C 32 Diagnostics simulation mode Not an error, diagnostic info, measurement OK
Sensor F 34 Measuring error, sensor Check sensor connection
Sensor F 35 Short-circuit, sensor Check sensor connection
Sensor F 36 Wire break, sensor Check sensor connection
Sensor F 37 Range overshot, sensor Check measuring limits
Sensor F 38 Range undershot, sensor Check measuring limits
Installation / Configuration I 41 Single-point adjustment active, sensor Status info; not an error
Installation / Configuration I 42 Two-point adjustment active, sensor Status info; not an error
Installation / Configuration F 65 Configuration defective Check configuration:
• Incorrect device
• Measuring span is too small
• Incorrect configuration data
Installation / Configuration C 71 Reconfiguration is running Status info; not an error
Operating conditions F 72 Error in the application Check configuration, connections; reset to
factory settings
Installation / Configuration I 74 Analog output adjustment active Status info; not an error
Installation / Configuration C 75 Analog output in simulation Status info; not an error
Operating conditions S 76 Values overshot Check parameters:
• Sensor limits up-scaled
• Measuring span is too small
Note
If the remedial measures listed for the error message do not improve the status of the device, please consult ABB Service.
