ABB TTF200 - Parameter Descriptions

TTF200 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF200-EN REV. B 27
Parameter descriptions
DTM menu path, parameters Description
<Device> / <Extras>
<Write Protection> Activates write protection for the entire device
• Yes: locked, entry combination: ≠ 0110
• No: unlocked, entry combination: 0110
<Device reset> Configuration data is reset to factory settings
(see Factory settings on page 29).
<Factory reset> Configuration data is reset to factory settings
(see Factory settings on page 29).
In addition, the adjustment data and DAC adjustment values are also reset to factory settings.
• Yes / OK
<Device> / <Configuration>
<Sensor / Sensor type> Selects sensor type:
• Pt100 (IEC751)
• Pt1000 (IEC751)
• Thermocouple type K (IEC584)
• Thermocouple type B (IEC584)
• Thermocouple type C (ASTME988)
• Thermocouple type D (ASTME988)
• Thermocouple type E (IEC584)
• Thermocouple type J (IEC584)
• Thermocouple type N (IEC584)
• Thermocouple type R (IEC584)
• Thermocouple type S (IEC584)
• Thermocouple type T (IEC584)
• Thermocouple type L (DIN43710)
• Thermocouple type U (DIN43710)
• Thermal voltage -125 to 125 mV
• Thermal voltage -125 to 1100 mV
• Resistance 0 to 500 Ω
• Resistance 0 to 5000 Ω
• Pt10 (IEC751)
• Pt50 (IEC751)
• Pt200 (IEC751)
• Pt500 (IEC751)
• Pt10 (JIS1604)
• Pt50 (JIS1604)
• Pt100 (JIS1604)
• Pt200 (JIS1604)
• Pt10 (IMIL24388)
• Pt50 (IMIL24388)
• Pt100 (MIL24388)
• Pt200 (MIL24388)
• Pt1000 (MIL24388)
• Ni50 (DIN43760)
• Ni100 (DIN43760)
• Ni120 (DIN43760)
• Ni1000 (DIN43760)
• Cu10 (OIML R 84), a=4270
• Cu100 (OIML R 84), a=4270
<Sensor / Connection> Sensor connection type relevant for all Pt, Ni, Cu resistance thermometers
• Two-wire: sensor connection type in two-wire technology
• Three-wire: sensor connection type in three-wire technology
• Four-wire: sensor connection type in four-wire technology
<Sensor / Line resistance> Sensor line resistance relevant for all Pt, Ni, Cu resistance thermometers with a two-wire circuit
Value range: 0 to 100 Ω
