6.1 General Data
Ordering information
Product designation UNITROL
1000-PM40
Device designation Power Module 40 A
Type UNS 2114A-Z
Order number: Basic equipment 3BHE015411 R0001
Mechanical data
Weight 6.7 kg
Protection class IP20
Dimensions (LxWxH) 220x285x154 mm
Climatic stability
Temperature range for operation 0 to +55 °C
Temperature range for storage -20 to +75 °C
Vibration IEC 60255-21-1, class 2
Shock IEC 60255-21-2, class 2
Seismic IEC 60255-21-3, class 2
Electrical data
Power supply Upwr: - DC 16 to 300 V DC, DC
- Single phase 30 to 250 V AC, 40 to 600 Hz
- Three phase 9 to 250 V AC, 0 to 600 Hz
Excitation output current Ie: - Maximum continuous current until 55 °C 40 A
- Overload for maximum 10 s 80 A
Excitation output voltage 0 to 350 V DC
Test voltage:
Power supply Upwr against case, relay contact and CAN Bus 3 kV DC, 2 s
Relay contact against case 2 kV AC, 1 min.
Relevant standards, CE conformity
EMC directive: 89/336/EEC
Generic emission standard *) IEC 61000-6-4
Product standard emission IEC 61800-3, Annex D
Generic immunity standard IEC/EN 61000-6-2
*) The emission limit values are kept only if the supply circuits Upwr is fed through a filter and the
power circuits are fitted with shielded cables.
