Document number Lang. Rev. ind. Page
ABB Switzerland Ltd
3BHS200200 E80
en A 7
2 DEVICE DESCRIPTION
2.1 Introduction
UNITROL 1000-PM40 is a power module of the latest design for the regulation of synchronous
generators and synchronous motors. The unit contains the most advanced microprocessor technology
together with IGBT semiconductor technology (Insulated Gate Bipolar Transistor).
Five LED's are integrated to provide status data in the cover, which signal the operating condition of the
equipment.
The mechanical structure consists of a heat sink mounted with a printed circuit board, two sidewalls and
a cover. This mechanical construction is extremely compact and robust. The plug connectors and the
connection terminals are integrated into the front of print circuit board.
2.2 Area of application
This advanced-design power module is used for the excitation of indirectly excited synchronous
machines. This unit is only suitable for this one area of application in connection with the automatic
voltage regulator UNITROL 1000-15.
