ABB Vmax 12 User Manual

DISTRIBUTION SOLUTIONS
99
1
4
5
6
7
8
9
9
9
10
12
11
2
3
Caption
1 Lever for manual closing spring charging
2 Signalling device for circuit breaker open/closed
3 Rating plate
4 Opening pushbutton
5 Closing pushbutton
6 Undervoltage release mechanical override (on request)
7 Signalling device for closing springs charged/discharged
8 Operation counter
9 Terminals
10 Earthing hole
11 Passage for the auxiliary circuit cord
12 Auxiliary contacts
Fig. 4
