Operation Manual / 4 Product description / A100-L
6 Periodic maintenance / 6.1 Foreword to maintenance
© Copyright 2018 ABB. All rights reserved.
HZTL4034_EN
Revision N
November 2018
6
Periodic maintenance
6.1
Foreword to maintenance
Maintenance work includes regular visual controls and cleaning operations which are inten-
ded to ensure the trouble-free functioning of the turbocharger.
Described maintenance points:
¡
Filter silencer
¡
Compressor
¡
Turbine and nozzle ring
Page 30 / 110
