Operation Manual / 4 Product description / A100-L
2 Removal and installation / 2.1 Turbocharger weight
© Copyright 2018 ABB. All rights reserved. HZTL4034_EN Revision N November 2018
2 Removal and installation
2.1 Turbocharger weight
Lifting gear with a sufficient load limit must be used for transporting the turbocharger. The
weight specified below applies to the heaviest variant possible. Depending on the specifica-
tion, the weight specified on the rating plate may be lower than the standard value specified
here.
Product Weight [kg]
A165-L 2300
A170-L 3300
A175-L 5600
A180-L 7500
A185-L 10500
A190-L 13500
Table2: A100-L Weights
2.2 Removing the turbocharger
WARNING
Risk of tipping
If the turbocharger is not sufficiently supported or not supported at all dur-
ing removal and installation, it may tip over and cause severe injury to per-
sonnel or accidents resulting in fatalities.
u Support the turbocharger at a suitable location.
u Secure with lifting gear wherever possible.
Wear safety helmet.
u Loosen cable to speed sensor.
u Disconnect all pipes according to the instructions of the enginebuilder.
u Check lifting gear.
u Fasten lifting gear on suspension eyes of the bearing casing and tauten.
Page 8 / 110
