Page #133 background imageLoading...
Page #133 background image
Operation Manual / 4 Product description / A100-L
12 Spare parts / 12.2 View of turbocharger with part numbers
© Copyright 2018 ABB. All rights reserved. HZTL4034_EN Revision N November 2018
Turbocharger
Part number Designation
- - Cartridge group
51001 Gas inlet casing
56001 Nozzle ring
51086 Threaded stud
51087 Hexagon nut
56011 (in the customer spare part set) Washer
56014 (in the customer spare part set) Hexagon-head screw
57001 Cover ring
57005 Hexagon-head screw
61001 Gas outlet casing
61009 Hexagon-head screw
68002 Foot, turbine end
72000 Compressor casing
72002 Threaded stud
72003 (in the customer spare part set) Washer
72004 (in the customer spare part set) Hexagon nut
72011 Hexagon-head screw
74040* Air outlet silencer (option)
74042* Gasket (option)
77000 Wall insert
77015 (in the customer spare part set) Hexagon-head screw
77040 (in the customer spare part set) O-ring
79000 Diffuser
79020 (in the customer spare part set) O-ring
79021 (in the customer spare part set) O-ring
81000 Filter silencer
81300* Insulation ring (option)
81301* Gasket (option)
81302* Insulating disc (option)
Table53: Turbocharger with part numbers
* Depending on the specification of the turbocharger
