Fig. 2.2.1.1: Installation of the floor frame
1
2
- Earth the completely assembled frame. Further details on
this can be found in the order documents.
?
When applying the floor topping, carefully fill under
the foundation frame with topping material.
1
5
3
55 ± 5
< 3
Section A-A
Floor topping
Top of finished floor
2
4
1
1
A
A
7
