Double-strap conguraons
Opon 1 – Loop and charger on opposite sides
1. Release the counterweight from the charger pocket.1.
2. Grasp the plasc buckle so the charger pocket is hanging toward your feet.2.
NOTE: If your generator is located on the right side of your body, grasp the buckle
with your right hand. If your generator is on your le side, grasp the buckle with
your le hand.
3. Put the arm on the opposite side of your generator through the loop.3.
Figure 6. Arm through loop on opposite side of generator
4. Adjust the charging apparel so that a strap is comfortably over your shoulder and the4.
other strap is under your armpit. The buckle should be in front of you.
5. Ensure that the charger is posioned over your generator.5.
6. Fasten the buckle.6.
NOTE: If needed, use the excess strap near the buckle to ghten or loosen the
apparel.
Opon 2 – Loop and charger on same side
1. Release the counterweight from the charger pocket.1.
2. Grasp the charger pocket so the long strap is hanging toward your feet.2.
NOTE: If your generator is located on the right side of your body, hold the pocket
with le hand. If your generator is on your le side, hold the pocket with your
right hand.
3. Insert the opposite arm (the arm that is not holding the charger pocket) through the3.
loop.
Figure 7. Arm through loop on same side as generator
4. Adjust the charging apparel so that a strap is comfortably over your shoulder and the4.
other strap is under your armpit. The buckle should be in front of you.
5. Ensure that the charger is posioned over your generator.5.
